PE42724 75Ω Wired SPDT Broadband RF switch for DOCSIS3.1 devices

    SG$ 6.05 SG$ 6.05 6.0469 SGD

    US$ 4.46

    This combination does not exist.

    Add to Cart

    SPDT, DOCSIS3.X, Reflective RF Switch

    Terms and Conditions
    30-day money-back guarantee
    Shipping: 2-3 Business Days

    Psemi


    pSemi Corporation is a Murata company driving semiconductor integration. pSemi builds on Peregrine Semiconductor’s 30-year legacy of technology advancements and strong IP portfolio but with a new mission—to enhance Murata’s world-class capabilities with high-performance semiconductors. With a strong foundation in RF integration, pSemi’s product portfolio now spans power management, connected sensors, optical transceivers, antenna tuning and RF frontends. These intelligent and efficient semiconductors enable advanced modules for smartphones, base stations, personal computers, electric vehicles, data centers, IoT devices and healthcare.


    FIND OUT MORE

    Overview

    The PE42724 is a HaRP™ technology-enhanced reflective SPDT RF switch designed for use in cable applications including DOCSIS 3.0/1 cable modem, set-top box and residential gateway. It delivers high linearity, excellent harmonics performance, and high surge immunity in the 5–1794 MHz band. It also features low insertion loss and high isolation performance making the PE42724 ideal for DOCSIS 3.1 applications.

    Features

        Supports DOCSIS 3.0/1 requirements
        Exceptional harmonics
        2fo of –121 dBc @ 17 MHz
        3fo of –150 dBc @ 17 MHz
        Best in class linearity across the frequency band
        Low insertion loss and high isolation performance
        Insertion loss of 0.3 dB @ 1218 MHz
        Isolation of 39 dB @ 204 MHz
        Packaging: 12-lead 3 × 3 × 0.75 mm QFN
