PE4152 Low Frequency Passive Mixer with Integrated LO Amplifier

    SG$ 21.12 SG$ 21.12 21.12 SGD

    US$ 15.88

    This combination does not exist.

    Add to Cart

    High-Linearity MOSFET Quad Mixer with LO amplifier

    Terms and Conditions
    30-day money-back guarantee
    Shipping: 2-3 Business Days


    pSemi Corporation is a Murata company driving semiconductor integration. pSemi builds on Peregrine Semiconductor’s 30-year legacy of technology advancements and strong IP portfolio but with a new mission—to enhance Murata’s world-class capabilities with high-performance semiconductors. With a strong foundation in RF integration, pSemi’s product portfolio now spans power management, connected sensors, optical transceivers, antenna tuning and RF frontends. These intelligent and efficient semiconductors enable advanced modules for smartphones, base stations, personal computers, electric vehicles, data centers, IoT devices and healthcare.



    The PE4152 is a high linearity quad metal-oxide-semiconductor field-effect transistor (MOSFET) mixer with an integrated local oscillator (LO) amplifier. The LO amplifier allows for LO input drive levels of less than 0 dBm to produce third-order intercept point (IIP3) values similar to a quad MOSFET array driven with a 15 dBm LO drive. The PE4152 operates with differential signals at the radio frequency (RF) and intermediate frequency (IF) ports and the integrated LO buffer amplifier drives the mixer core. It can be used as an upconverter or a downconverter.

    The PE4152 also offers an integrated LO amplifier bypass option providing additional flexibility for low power or increased linearity operation. The bypassed LO amplifier allows superior LO to RF and LO to IF isolation levels relative to the enabled mode


        Ultra-high linearity quad MOSFET array with integrated LO amplifier
        Ideal for mobile radio and up or down-conversion applications
        Low conversion loss
        High LO isolation
        RoHS-compliant 10-lead MSOP package
        Ideal for highly magnetic environments
        Packaging: 10-lead 3 × 3 × 0.86 mm MSOP
